Testermeter-FST800-1400 Air Conditioner Pressure Sensor

Main Feature : Testermeter-FST800-1400 Air Conditioner Pressure Sensor
Serial No. : Owen0143

Specification

Contact Us For Quotation

Email: 464560351@qq.com

Whatsapp&Wechat:+8618620373879

Testermeter-FST800-1400 Air Conditioner Pressure Sensor

【Product Description】

FST800-1400 air conditioner pressure sensor is used to measure the refrigerant pressure in the air conditioning system for real-time monitoring, reducing idle speed and saving energy, etc. The product has the characteristics of fast response speed and good compatibility with measurement. Widely used in compressors, refrigeration and air-conditioning equipment, petroleum, chemical, industrial fluids and other equipment.

【Technical Parameters】

Measuring medium	R22, R407C, R134A
Pressure Range(bar)	0~20 0~46
Signal Output	0.5~4.5VDC
Signal Line Specification	3 Wire
Supply Voltage	5VDC
Accuracy	±1.5 %FS
Full error band	-30~+100°C
Operating temperature	±0.02 %FS/°C
Storage temperature	-30~+120°C
Overload pressure	200% FS
Destruction pressure	300% FS
Vibration	11g (50~2000Hz)
Supply current	1 0mA (maximum)
Electrical connections	YAZAKI RK03FB
Protection level	IP65
Material	304 stainless steel
Service life	5 million full scale cycles
Pressure interface	Φ6*1.0 pipe connection
Load Resistance	10KΩ (typical)
Overvoltage protection	16VDC
Reverse voltage	-14VDC

【External structure】

图片关键词

【Detailed description】

图片关键词

图片关键词

图片关键词

图片关键词

Lable: Testermeter-FST800-1400 Air Conditioner Pressure Sensor
