WP3084ADAM 8VI 0-10V Analog Input Voltage Acquisition

Main Feature :
Serial No. : Zoe671

Specification

Contact Us For Quotation

Email: 464560351@qq.com

Whatsapp&Wechat:+8618620373879

Testermeter- WP3084ADAM 8VI 0-10V Analog Input Voltage Acquisition Module RS485 MODBUS RTU Communication WELLPRO

Product Description

Eight voltage input channels: DC0 - 10V.

RS485 MODBUS RTU standard communication protocol.

Can be networked with configuration software, programmable logic controllers, or industrial touch panels.

Communication status LED.

Communication circuit designed for lightning protection and anti - interference.

Used for signal acquisition and control in industrial fields.

2. Specifications

Analog input channels: 8ch.

Analog input range: DC0 - 10V.

Analog input accuracy: ±0.02V.

Operating temperature: -20 - 70 ℃.

External power supply: DC9V - 30V/2W.

Isolation protection: DC1500V.

Installation method: Standard DIN rail or screws.

Dimensions: 125 × 73 × 35mm.
