Testermeter- SW14533 SW Series Single-Axis Accelerometer

Testermeter- SW14533 SW Series Single-Axis Accelerometer

2025-05-28 22:05:12

SW13533 SW Series Single Axis Accelerometer

  • Main Feature :
  • Serial No. : Zoe771
Contact Us For QuotationEmail:  464560351@qq.comWhatsapp&Wechat:+8618620373879

SW13533 SW Series Single Axis Accelerometer



SW series accelerometers are traditional accelerometer based on piezoelectric ceramics technology, using imported ceramic sensing element, titanium shell and 1/4-28 4-Pin connector. Performance and appearance can be comparable with leading competitors’ products.

BSWA has a strict quality control system and each accelerometer has to pass environmental experiments with military standard before it leaves the factory, which lead to meet the needs of defense field or routine testing. Accelerometer cable is the most easily damaged parts and BSWA has enhanced the connectors and cables to improve the life of product.



Features:

• ICCP Power Supply Triaxial Accelerometer

• Small Size And Light Weight

• Imported Ceramic Sensing Element

• Optional Various Sensitivity



Application:

• Routine Vibration Testing

• Automotive, Railway And Aerospace NVH

• Modal Analysis

• OPTA Testing

Specification

Value

Model

SW13533

Direction of Measurement

triaxial

Sensitivity (±5%)

50mV/g

Measurement Range

±100g peak

Frequency Response (±5%)

x Axis: 1.0Hz ~ 8kHz
y Axis: 1.0Hz ~ 6kHz
z Axis: 1.0Hz ~ 5kHz

Frequency Response (±10%)

x Axis: 0.5Hz ~ 10kHz
y Axis: 0.5Hz ~ 8kHz
z Axis: 0.5Hz ~ 6kHz

Resonant Frequency

45kHz

Broadband Resolution

0.0002g rms

Non - Linearity

-

Transverse Sensitivity

-

Maximum Shock Level

±800g peak

Overload Limit (Shock)

±2000g peak

Operating Temperature

-50°C ~ 120°C

Base Strain Sensitivity

0.0008g/με

Excitation Voltage

18VDC ~ 30VDC

Constant Current Excitation

2mA ~ 20mA

Output Impedance

≤100Ω

Output Bias Voltage

9VDC ~ 11VDC

Spectral Noise (10Hz)

24μg/√Hz

Spectral Noise (100Hz)

8μg/√Hz

Spectral Noise (1kHz)

6μg/√Hz
