Testermeter-SSR25DAS Single Phase Solid State Relay 25A 5V Rated Voltage Max Switching Current Miniature Size with Sealed Protection

Main Feature : Testermeter-SSR25DAS Single Phase Solid State Relay 25A 5V Rated Voltage Max Switching Current Miniature Size with Sealed Protection
Serial No. : Owen0450

Specification

Contact Us For Quotation

Email: 464560351@qq.com

Whatsapp&Wechat:+8618620373879

Testermeter-SSR25DAS Single Phase Solid State Relay 25A 5V Rated Voltage Max Switching Current Miniature Size with Sealed Protection

Features

Rapid Response and Low Interference

Zero Cross triggering technology ensures conduction at the zero point of AC voltage, significantly reducing electromagnetic interference (EMI), making it suitable for controlling sensitive equipment. Switch response time ≤10ms, supporting high-frequency switching (such as PID regulation in temperature control systems).

Reliability Design Built-in overheat protection circuit (120℃ threshold) to prevent device damage caused by overload. Off-state leakage current ≤2mA, with extremely low power consumption in the off state, suitable for energy-saving applications

Specification

item	value
Contact Load	Low Power
Place of Origin	China
	Guangzhou
Power Source	AC/DC
Contact Material	Copper
Contact Form	1NO
Max. switching voltage	480V
Max. switching current	25A
Terminal Shape	Screw Terminal
Rated Current	25A
Brand Name	NA
Model Number	SSR-25DA
Theory	Solid State Relay
application	General Purpose
Size	Miniature
Protect Feature	Sealed

Lable: SSR25DAS Single Phase Solid State Relay, 25A 5V Rated Voltage Max Switching Current, Miniature Size with ,Sealed Protection
