Testermeter-MIK-LDG Plus Discount Sewage Split Electromagnetic magnetic flow meter

2024-08-03 14:30:51

Main Feature :
Serial No. : Lisa0674

Specification

Email: 464560351@qq.com

Whatsapp&Wechat:+8618620373879

Teatermeter-MIK-LDG Plus Discount Sewage Split Electromagnetic magnetic flow meter

Features

Converter
Compact Type	IP65
Remote Type	IP65(IP68 optional)
Measurement sensor
Nominal Diameter	DN15-DN1000
Pressure rating (High pressure can be customized)	DN6 - DN80, PN<4.0MPa
	DN100 - DN150, PN<1.6MPa
	DN200 – DN1000, PN<1.0MPa
	DN1200 – DN2000, PN<0.6MPa
Lining Material	Chloroprene rubber (CR), Polytetrafluoroethylene (PTFE/F4), Fluorinated ethylene propylene (FEP/F46), Teflon(PFA)
Electrode Material	316L Stainless Steel, Hastelloy C, Hastelloy B, Ti, Ta, Pt
IP Rate	IP68	IP65
Medium temperature	-25 – 180℃	-10 – 80℃
Serial communications	RS-485
Output	Current (4-20 mA) , pulse , frequency , state switch
Max measuring error	Measurement value ±0.5%（Flow speed > 1m/s）； Measurement value ±0.5% ±2mm/s（Flow speed <1m/s）
Repetitiveness	0.15%
Power supply	100-240VAC，50/60Hz, 22VDC—26VDC
Power consumption	Max 15VA
Signal cable	Apply only to remote type
Shielded cable	Signal section，wire: 0.5mm2 Cu /AWG20

Key attributes

Type

Variable Area Water Flowmeters, Electromagnetic flowmeter

Material

316 Stainless Steel

Place of Origin

Guanghzou, China

Warranty

12 months

Customized support

OEM, ODM

Brand Name

Xtester

Model Number

MIK-LDG

Diameter Nominal

DN10 ~ DN1000

Accuracy

±0.3%, ±2mm/s (flowrate less than 1m/s)

Conductivity

water 20μS/cm other medium 5μS/cm

Ambient Temperature

-10℃~60℃

Power Supply

100-240VAC, 50/60HZ

Liner Material

PFA,F46,Neoprene,PTFE, FEP

PH electrode

316 stainless steel, HC/HB, Ti, Da, Pt

Protection class

IP65 or IP68

OEM

Yes
