Testermeter- TD1855 Multifunction Calibrator ACDC voltage source
| TD1855 is a multi-function calibrator, integrates AC\DC voltage source, AC\DC current source, DC resistance source, etc. The accuracy class is 0.05. It’s applied to calibrating 3.5 digits multimeter, voltmeter, ammeter, ohmmeter, power meter. |
Summary
| TD1855 is a multi-function calibrator, integrates AC\DC voltage source, AC\DC current source, DC resistance source, etc. The accuracy class is 0.05. It’s applied to calibrating 3.5 digits multimeter, voltmeter, ammeter, ohmmeter, power meter. |
Features
• DC voltage output: 20 mV ~ 1100 V
• DC current output: 2 μA ~ 22 A(33 A is optional)
• AC voltage output: 20 mV ~ 1100 V
• AC current output: 200 μA ~ 22 A(33 A is optional)
• Sinusoidal wave frequency: 45 Hz ~ 1100 Hz
• Simulated DC resistance: 10 Ω ~ 220 MΩ
• 2 MHz square wave frequency output
• Phase output
• AC/DC power output
• Remote adjustment (optional)
• Clamp meter calibration (optional)
• Transducer calibration(optional)
• 5.6-inch Color Touch Screen |
Calibrate AC\DC electrical measuring instruments
• DCV output: 20 mV ~ 1100 V • DCI output: 2 μA ~ 22 A\33 A • ACV output: 20 mV ~ 1100 V, 45 Hz ~ 1100 Hz • ACI output: 200 μA ~ 22 A\33 A, 45 Hz ~ 1100 Hz • RES output: 10 Ω ~ 220 MΩ • Frequency output: 1 Hz ~ 2 MHz • Calibrate digital multimeter, AC/DC voltmeter, AC/DC ammeter, DC ohmmeter, frequency meter. |
