Testereter-DEV330 DC Fast EV Charging Station Floor Mounted 2 Channel Charger kwh Meter

Main Feature :
Serial No. : monica0686

Specification

Contact Us For Quotation

Email: 464560351@qq.com

Whatsapp&Wechat:+8618620373879

Testereter-DEV330 DC Fast EV Charging Station Floor Mounted 2 Channel Charger kwh Meter

Product Introduction

PD195Z-CD31F is a DC rail-mounted electric energy meter designed and developed by ELECNOVA for EV Charger. The product can measure 1000V DC voltage, and a variety of auxiliary power supplies can be selected to adapt to different application environments of customers. Through the RS485 communication interface, it can be easily integrated with various intelligent power distribution systems and energy management systems to share monitoring data.

Technical Parameter

Accuracy		U/I/P 0.5, Energy 1
Data refresh rate		1s
Measuring	Voltage	Input	DC 1000V
			50V~1200V
			0.20%
	Current	Input	DC 75mV
		Range	0.002In~1.2In
		Accuracy	0.20%
	Power	Accuracy	0.50%
Power supply	Working range		AC/DC 80~270V, DC24, DC12V
	Power Consumption		≤1W
Communication			RS485, Modbus-RTU
Communication			Baud rate 1200~38400bps
Protection level			IP20
Working temperature			-10~85℃
Relative humidity			≤95%RH
Pollution class			2
Altitude			2000m

Lable: DEV330 DC Fast EV Charging Station
