Xtester- 2023 NEW UNI-T UTi120S Cheap Price 120*90 Resolution Mobile Phone Laptop Repairing Handheld Digital Thermal Imager Camera
Products Description
This is an economical hand-held infrared thermal imager, integrated with image temperature measurement, light and portable, with complete functions, temperature measurement range of - 20~400 ℃, infrared resolution of 10800, central point temperature measurement and high and low temperature automatic tracking, and equipped with LED lighting/laser indication/high and low temperature alarm, IP54/two-meter fall-proof three-proofing design, which makes it easier for you to cope with different working environments, In addition to the temperature measured by the device itself, the temperature can also be taken and stored according to the demand. The infrared image analysis software provided can help you understand every detail in the later analysis. FEATURE 1. Infrared resolution: 120 × 90 2. Temperature measurement range: - 20~400 ℃ 3. Temperature measurement mode: center point, high and low temperature tracking 4. Photo storage: 16GB TF card 5. High and low temperature alarm: image, beep, LED flashing 6. Laser indicator/LED light 7. Three-proof design: IP54/two-meter fall-proof 8. PC analysis software 9. Six color palettes available 10. Emissivity adjustable 11. The use time shall not be less than 9 hours 12. 3.7V/2600mAh rechargeable lithium battery 13. Bottom design ¼ Screw hole can be used with tripod. |
Product Paramenters
Model | UTi120S |
General Characteristics | |
IR resolution | 120x90 pixels |
Screen Display | 2.4”TFT |
Field of view (FOV) | 50°x38° |
Thermal sensitivity (NETD) | 60mk |
Spatial resolution (IFOV) | 7.3mrad |
Focus | Focus free |
Frame rate | 25Hz |
Object Temperature range | -20~400℃ |
Measurement accuracy | ±2℃ or ±2% whichever is greater |
Battery operating time | 8hours |
Functions | |
Palettes | 6 |
Emissivity | Adjustable (0.01-0.99) |
Image Model | Thermal |
LED | √ |
Auto tracking for Lo/Hi temperature | √ |
Alarm | √ |
Storage | 16G Micro SD Card |
PC software | Analysis |
Protection | IP54/2m |
Communication interface | Type-C |
Package | |
Product net size | 196 x 63 x 75mm |
Product net weight | 310g |
Standard accessories | Type-C USB cable, Manual |
