Testermeter-auto 60 degree paint gloss test meter
| Designed according to the national verification regulation of JJG696 standard, adopt long life light source, good repeatability, small volume, high precision and good stability. It is mainly used coatings, printing ink, paint, paint, wood, marble, granite, polishing brick, brick of pottery and porcelain, plastic, paper, metal and non-metallic materials to the surface of the mirror gloss measurement, more stable performance, more durable, more comfortable |
Function:
(1) One button to complete triangle measurement: one operation can complete three angle measurement; Measuring light incident angle meet ISO 2813 three measuring light incident angle. Three incident angle of mirror gloss meter is 20 °, 60 °, 85 ° respectively (2) Optional angle mode: choose measuring angle or angle combination according to user needs. (3) Manually entering standard samples gloss data (4) Humanized design, good man-machine communication interface (5)Three angle can store 50000 testing records, storage structure is: 100 prototypes, each prototype with 500 testing data (6) Data browsing and viewing function (7) The machine has automatic shutdown function, low power warning functions, full data storage hint functions (8) USB communication interface to communicate with PC (9) PC software can be extended more functions. |
Specification
Specification | SKZ117B | SKZ117A |
Measuring Angle | 20° 60° 85° | 60° |
Measuring Range | 20°:0-2000GU 60°:0-1000 GU 85°:0-160 GU | 60°: 0-1000 |
Measuring Spot | 20°: 10x10 mm 60°:9x15 mm 85°:5x18 mm | 60°: 9x15 |
Measuring Spot | 0-1000:0.1 GU, 1000-2000:1 GU | |
Repeatability | 0-100:0.2 >100:0.2% GU | |
Indication Error | ±1.5 GU | |
Zero Error | 0.2 GU | |
Working Temperature | 10℃ - 40℃ | |
Storage Temperature | -10℃ - 70℃ | |
Humidity Range | less than 85%,without condensation | |
Power Adapter | Section 2 5 alkaline batteries/power adapter | |
Volume | 159x49x72 mm | |
Weight | 500 g | |
