Testerneter-CE SDI12 Mini 10 in 1 Easy Install Agricultural LORA LORAWAN GPRS 4G WIFI Highway Weather Station

  • Main Feature :
  • Serial No. : Lisa0844
Contact Us For QuotationEmail:  464560351@qq.comWhatsapp&Wechat:+8618620373879

Testerneter-CE SDI12 Mini 10 in 1 Easy Install Agricultural LORA LORAWAN GPRS 4G WIFI Highway Weather Station

Product Description

Measurement parameters
Parameters Name
10 in 1:  Temperature, Humidity, Wind speed, Wind direction, Air pressure,  PM2.5,                      PM10, Rainfall，Noise，Illumination/solar radiation
Parameters
Measure range
Resolution
Accurancy
Air temperature
-40-60℃
0.01℃
±0.3℃（25℃）
Air relative humidity
0-100%RH
0.01%RH
±3%RH(<80%RH)
Atmospheric pressure
500-1100hpa
0.1hpa
±0.5hpa（0-30℃）
Wind speed
0-60m/s
0.01m/s
±（0.3+3%V）m/s
Wind direction
0-359.9°
0.1°
±3°
PM2.5
0-500ug/m³
1ug/m³
±(10+10%)ug/m³
PM10
0-500ug/m³
1ug/m³
±(10+10%)ug/m³
Rainfall
0-200mm/h
0.2mm
±15%
Noise
30-130dB
±1.5dB
0.1dB
Illumination/solar radiation
0-200KLux
10Lux
±3% or 1%F.S
0-2000W/㎡
1W
±5%
* Other customizable parameters
Ultraviolet,CO2,CO,NO2,SO2,O3,H2S,TVOC
Monitoring principle
Air temperature and humidity: Swiss Sensirion digital temperature and humidity sensor
Wind speed and direction: Ultrasonic sensor

Technical parameter
Stability
Less than 1% during the life of the sensor
Response time
Less than 10 seconds
Warm-up time
30S
Supply voltage
9-24VDC
Working current
DC12V≤180ma
Power consumption
DC12V≤2.16W
Life time
In addition to SO2 \ NO2 \ CO \ O3 \ PM2.5 \ PM10 (normal environment for 1 year, high pollution environment is not guaranteed),
life is not less than 3 years
Output
RS485, MODBUS communication protocol
Housing material
ASA engineering plastics which can be used for 10 years outside
Working environment
Temperature -30 ～ 70 ℃, working humidity: 0-100%
Storage conditions
-40 ~ 60 ℃
Standard cable length
2 meters
The farthest lead length
RS485 1000 meters
Protection level
IP65
Electronic compass
Optional
GPS
Optional
Wireless transmission
Wireless transmission
LORA / LORAWAN(eu868mhz,915mhz,434mhz), GPRS, 4G,WIFI
Mounting Accessories
Stand pole
1.5 meters, 2 meters ,3 meters higth, the other higth can be customize
Equiment case
Stainless steel waterproof
Ground cage
Can supply the matched ground cage to burried in the ground
Lightning rod
Optional(Used in thunderstorm places)
LED display screen
Optional
7 inch touch screen
Optional
Surveillance cameras
Optional
Solar power system
Solar panels
Power can be customized
Solar Controller
Can provide matched controller
Mounting brackets
Can provide the matched bracket

图片关键词图片关键词图片关键词




Lable: SDI12 Mini 10 in 1
