Testermeter-AS 220.R2 PLUS Analytical Balance
Functions Datasheet
AS 220.R2 PLUS Analytical Balance WL-104-0177 | |
Metrological parameters | |
Maximum capacity [Max] | 220 g |
Minimum load | 10 mg |
Readability [d] | 0,1 mg |
Verification unit [e] | 1 mg |
Tare range | -220 g |
Standard repeatability [5% Max] | 0,07 mg |
Standard repeatability [Max] | 0,08 mg |
Standard minimum weight (USP) | 140 mg |
Standard minimum weight (U=1%, k=2) | 14 mg |
Permissible repeatability [5% Max] | 0,09 mg |
Permissible repeatability [Max] | 0,1 mg |
Linearity | ±0,2 mg |
Stabilization time | 2 s |
Adjustment | internal (automatic) |
OIML Class | I |
Physical parameters | |
Leveling system | manual |
Display | 5,3”LCD (backlit) |
Weighing chamber doors | manual |
Delivery components | Balance, weighing pan, weighing pan shield, bottom cover, power supply. |
Weighing pan dimensions | ø100 mm |
Packaging dimensions W x D x H | 490×400×520 mm |
Net weight | 6,95 kg |
Gross weight | 9 kg |
Construction | |
Protection class | IP 43 |
Communication interface | |
Communication interface | 2×RS232¹, 2×USB-A (interchangeable), USB-B, Wi-Fi (option) |
Electrical parameters | |
Power supply | Adapter: 100 一 240V AC 50/60Hz 0,6A; 12V DC 1,2A Balance: 12 一 15V DC 0,4A max |
Power consumption max. | 3 W |
Environmental conditions | |
Operating temperature +10 一 +40 °C | |
