testermeter-AR850+ Digital Non-Destructive Ultrasonic Thickness Meter 1.2~225mm Range Product Category Gauges
Product descriptions from the supplier
Product Description
FEATURES
| The usage of an ultrasonic thickness gauge for non-destructive testing to check material properties such as thickness measurement, is now regularly utilized in all areas of industrial measurements. The ability to gauge thickness measurement without requiring access to both sides of the test piece, offers this technology a multitude of possible applications. |
SPECIFICATIONS
Measuring Range | 1.2~225mm |
Accuracy | ±(1%H+0.1)mm |
Resolution | 0.1mm |
Sound Velocity | 1000~9999m/s |
Operating Frequency | 5MHz/2.5MHz |
Operation Condition | 0°C~40°C |
Sound Velocity Measuring & Storage | 12 groups |
Minimum limit for tube measuring | 10mm probe: 20*3mm(steel) |
Backlight Display | √ |
Auto Zero Calibration | √ |
Auto linear compensation | √ |
Coupling Indicator | √ |
Battery Indication | √ |
Auto/Manual Power Off | √ |
PACKING INFORMATION
Power | 3*1.5V AAA battery (not included) |
Product Net Weight | 275g |
Product Size | 75*153*35mm |
Packing | Gift Box |
Standard Quantity Per Carton | 12 |
Standard Carton Size | 52*43*32.5cm |
Standard Carton Gross Weight | 16.3KG |
